1.6 Definitions
the pricelist model configuration, not including a mattress
The value depends on the product configuration, accessories or
customer adjustments.
Clearance of Undercarriage
the height from the floor to the lowest point of the undercarriage
between the castors, for the manipulation of accessories under a
braked bed in the standard position
cycle of operation of the motor: time of activity/time of rest
Ergoframe is the kinematic system of Mattress support platform
Adjustment whose effect is the elimination of pressure on the patient´s
abdomen and pelvic area and frictional forces on the patient‘s back and
legs.
Maximum Patient Weight depends on the application environment
according to IEC 60601-2-52. For application environment 1
(intensive/critical care) and 2 (acute care) reduce Safe working Load by
65 kg. For application environment 3 (long-term care) and 5
(ambulatory care) reduce Safe working Load by 35 kg.
the highest allowable load on the bed (patient, mattress and
accessories)
the height of the upper crossbar or the edges of the siderails (not the
highest point of the siderail controls) from the patient surface
The height of the patient surface with regard to the floor is 400 mm
The mattress support platform, including the individual parts, has to
be in a horizontal (level - 0°) position.
The siderails are always locked in the upper position.
The basic position of the integrated extension.
1.7 Abbreviations
Cardiopulmonary Resuscitation
Electromagnetic Compatibility
Medical Electrical (Equipment)
Unique Device Identification (for medical devices)
