45
11.10.7 Monitor Tray
The monitor tray is suitable for transporting monitors with a weight of up to 15 kg.
Installing the monitor tray:
Insert two vertical monitor tray tubes into corner sleeves on foot end.
Fixate monitor with safety belts in order to avoid any damage during transport.
Fig. 27 Monitor Tray
11.10.8 Oxygen Bottle Holders
The oxygen bottle holders are suitable for transporting oxygen bottles with a weight of up to 15 kg (33.07 lbs) and a
volume of 5 litres.
Version A
Put oxygen bottle holder on transversal profile behind head end.
NOTE Using oxygen bottle holder 4MAR2010PC004 is not possible if the bed is equipped with an additional
adapter for a lifting pole.
Fig. 29a Oxygen Bottle Holder A
Risk of injury with oxygen bottle holder due to incorrect use or due to careless driving!
Ensure the oxygen bottle holder is correctly fitted in correct position.
It is necessary to place oxygen bottle holder (with or without O2 bottle) before transport
to secure transport position.
Be aware of people or objects in close proximity when driving or manipulating the bed
equipped with oxygen bottle holder.
Secure the oxygen bottles against falling or involuntary movement with rubber strap.
Place the oxygen bottle holder on the bed by instructions in the following text.
Ensure the oxygen bottle valve will not get damaged by careless or incorrect
manipulation or placement.
