17
Setup
Linksys
Port Range Forwarding
Port forwarding can be used to set up public services on your network. When
users from the Internet make certain requests to your network, the router
can forward those requests to computers that are equipped to handle the
requests. If, for example, you set the port number 80 (HTTP) to be forwarded
to IP address 192.168.1.2, then all HTTP requests from outside users will be
forwarded to 192.168.1.2.
To set up other services input the server TCP or UDP port number and the
virtual host IP addresses.
Service Select the service. You can also add a new service from
Service Management.
IP Address Input the LAN IP address of the virtual host.
Interface Select the WAN port. (Dual WAN router only)
Enable Check the box to enable this function.
Add to list Click the button to add a new entry.
Update Select the entry that you want to modify. Change the setting
and then click Update. Clicking Add New deselects the entry
and clears the text fields.
Delete Click the entry and then click Delete.
View To view the entry table, choose Port Range Forwarding or
Port Triggering.Click Refresh to renew the display. Click Close
to return to configuring page.
Adding a service
To add a new service item or to edit an existing service, click Service
Management. If the web browser displays a warning about the pop-up
window, click to allow the blocked content.
In the Service Management window, add or edit entries as needed. After
setting a rule, be sure to click OK to save your settings, or click Cancel to undo
them. To add a service to the list, enter the following information, and click
Add to List. You can have up to 30 services in the list.
