Littelfuse MPS - Page 118

Page E-8
MPS Motor Protection System Rev. 6-F-022117
Appendix E, Communications Database Table
MPS
REGISTER
(DECIMAL)
MODBUS
REGISTER
(DECIMAL)
A-B FILE
(DECIMAL)
(NOTE 4)
DESCRIPTION
ACCESS
RANGE
TYPE
363
ASD 4-mA Frequency
R/W
0 - 70 Hz
T1(Low)
364
T1(High)
365
ASD 20-mA Frequency
R/W
0 - 70 Hz
T1(Low)
366
T1(High)
367
Motor 4-mA Speed
R/W
0 - 100%
T1(Low)
368
T1(High)
369
Motor 20-mA Speed
R/W
0 - 100%
T1(Low)
370
T1(High)
Analog Output
372
Output Filter
R/W
0 - 1
T6
373
40374
3:373
Output Parameter
R/W
0 - 16
T15
(See Register 856-859 for Analog Output Calibration)
Network and I/O Module Communications
374
40375
3:374
DeviceNet Producing Instance
R/W
0 - 9
T82
375
DeviceNet Consuming Instance
R/W
0 - 4
T83
379
40380
3:379
RTD-Sensor-Error Alarm Action
R/W
0 - 7
T43
380
RTD-Module-Error Alarm Action
R/W
0 - 7
T43
381
Network Alarm Action
R/W
0 - 7
T43
382
Network Type
R/W
0 - 5
T16
383
Network Baud Rate
R/W
0 - 7
T17
384
Error Check
R/W
0 - 2
T18
385
Network ID
R/W
0 - 255
T1(Low)
386
T1(High)
387
Network Trip Action
R/W
0 - 7
T42
RTD Module
388
40389
3:388
RTD-Sensor-Error Trip Action
R/W
0 - 7
T42
389
RTD-Module-Error Trip Action
R/W
0 - 7
T42
390
40391
4:0
Number of RTD Modules
R/W
0 - 3
T19
RTD Type
391
40392
4:1
Module 1 #1 Type
R/W
0 - 4
T20
392
Module 1 #2 Type
R/W
0 - 4
T20
393
Module 1 #3 Type
R/W
0 - 4
T20
394
Module 1 #4 Type
R/W
0 - 4
T20
395
Module 1 #5 Type
R/W
0 - 4
T20
396
Module 1 #6 Type
R/W
0 - 4
T20
397
Module 1 #7 Type
R/W
0 - 4
T20
398
Module 1 #8 Type
R/W
0 - 4
T20
399
Module 2 #1 Type
R/W
0 - 4
T20
400
Module 2 #2 Type
R/W
0 - 4
T20
401
Module 2 #3 Type
R/W
0 - 4
T20
402
Module 2 #4 Type
R/W
0 - 4
T20
403
Module 2 #5 Type
R/W
0 - 4
T20
404
Module 2 #6 Type
R/W
0 - 4
T20
405
Module 2 #7 Type
R/W
0 - 4
T20
406
Module 2 #8 Type
R/W
0 - 4
T20
