Littelfuse MPS - Page 119

Page E-9
MPS Motor Protection System Rev. 6-F-022117
Appendix E, Communications Database Table
MPS
REGISTER
(DECIMAL)
MODBUS
REGISTER
(DECIMAL)
A-B FILE
(DECIMAL)
(NOTE 4)
DESCRIPTION
ACCESS
RANGE
TYPE
407
Module 3 #1 Type
R/W
0 - 4
T20
408
Module 3 #2 Type
R/W
0 - 4
T20
409
Module 3 #3 Type
R/W
0 - 4
T20
410
Module 3 #4 Type
R/W
0 - 4
T20
411
Module 3 #5 Type
R/W
0 - 4
T20
412
Module 3 #6 Type
R/W
0 - 4
T20
413
Module 3 #7 Type
R/W
0 - 4
T20
414
Module 3 #8 Type
R/W
0 - 4
T20
RTD Function
415
40416
4:25
Module 1 #1 Function
R/W
0 - 7
T21
416
Module 1 #2 Function
R/W
0 - 7
T21
417
Module 1 #3 Function
R/W
0 - 7
T21
418
Module 1 #4 Function
R/W
0 - 7
T21
419
Module 1 #5 Function
R/W
0 - 7
T21
420
Module 1 #6 Function
R/W
0 - 7
T21
421
Module 1 #7 Function
R/W
0 - 7
T21
422
Module 1 #8 Function
R/W
0 - 7
T21
423
Module 2 #1 Function
R/W
0 - 7
T21
424
Module 2 #2 Function
R/W
0 - 7
T21
425
Module 2 #3 Function
R/W
0 - 7
T21
426
Module 2 #4 Function
R/W
0 - 7
T21
427
Module 2 #5 Function
R/W
0 - 7
T21
428
Module 2 #6 Function
R/W
0 - 7
T21
429
Module 2 #7 Function
R/W
0 - 7
T21
430
Module 2 #8 Function
R/W
0 - 7
T21
431
Module 3 #1 Function
R/W
0 - 7
T21
432
Module 3 #2 Function
R/W
0 - 7
T21
433
Module 3 #3 Function
R/W
0 - 7
T21
434
Module 3 #4 Function
R/W
0 - 7
T21
435
Module 3 #5 Function
R/W
0 - 7
T21
436
Module 3 #6 Function
R/W
0 - 7
T21
437
Module 3 #7 Function
R/W
0 - 7
T21
438
Module 3 #8 Function
R/W
0 - 7
T21
RTD Trip1/Alarm1 Setpoints
446
40447
4:56
Module 1 #1 Trip Level
R/W
40 - 200°C
T1(Low)
447
T1(High)
448
Module 1 #1 Alarm Level
R/W
40 - 200°C
T1(Low)
449
T1(High)
450
Module 1 #2 Trip Level
R/W
40 - 200°C
T1(Low)
451
T1(High)
452
Module 1 #2 Alarm Level
R/W
40 - 200°C
T1(Low)
453
T1(High)
454
Module 1 #3 Trip Level
R/W
40 - 200°C
T1(Low)
455
T1(High)
