Littelfuse MPS - Page 120

Page E-10
MPS Motor Protection System Rev. 6-F-022117
Appendix E, Communications Database Table
MPS
REGISTER
(DECIMAL)
MODBUS
REGISTER
(DECIMAL)
A-B FILE
(DECIMAL)
(NOTE 4)
DESCRIPTION
ACCESS
RANGE
TYPE
456
Module 1 #3 Alarm Level
R/W
40 - 200°C
T1(Low)
457
T1(High)
458
Module 1 #4 Trip Level
R/W
40 - 200°C
T1(Low)
459
T1(High)
460
Module 1 #4 Alarm Level
R/W
40 - 200°C
T1(Low)
461
T1(High)
462
Module 1 #5 Trip Level
R/W
40 - 200°C
T1(Low)
463
T1(High)
464
Module 1 #5 Alarm Level
R/W
40 - 200°C
T1(Low)
465
T1(High)
466
Module 1 #6 Trip Level
R/W
40 - 200°C
T1(Low)
467
T1(High)
468
Module 1 #6 Alarm Level
R/W
40 - 200°C
T1(Low)
469
T1(High)
470
Module 1 #7 Trip Level
R/W
40 - 200°C
T1(Low)
471
T1(High)
472
Module 1 #7 Alarm Level
R/W
40 - 200°C
T1(Low)
473
T1(High)
474
Module 1 #8 Trip Level
R/W
40 - 200°C
T1(Low)
475
T1(High)
476
Module 1 #8 Alarm Level
R/W
40 - 200°C
T1(Low)
477
T1(High)
478
Module 2 #1 Trip Level
R/W
40 - 200°C
T1(Low)
479
T1(High)
480
Module 2 #1 Alarm Level
R/W
40 - 200°C
T1(Low)
481
T1(High)
482
Module 2 #2 Trip Level
R/W
40 - 200°C
T1(Low)
483
T1(High)
484
Module 2 #2 Alarm Level
R/W
40 - 200°C
T1(Low)
485
T1(High)
486
Module 2 #3 Trip Level
R/W
40 - 200°C
T1(Low)
487
T1(High)
488
Module 2 #3 Alarm Level
R/W
40 - 200°C
T1(Low)
489
T1(High)
490
Module 2 #4 Trip Level
R/W
40 - 200°C
T1(Low)
491
T1(High)
492
Module 2 #4 Alarm Level
R/W
40 - 200°C
T1(Low)
493
T1(High)
494
Module 2 #5 Trip Level
R/W
40 - 200°C
T1(Low)
495
T1(High)
496
Module 2 #5 Alarm Level
R/W
40 - 200°C
T1(Low)
497
T1(High)
498
Module 2 #6 Trip Level
R/W
40 - 200°C
T1(Low)
499
T1(High)
