Page E-11
MPS Motor Protection System Rev. 6-F-022117
Appendix E, Communications Database Table
MPS
REGISTER
(DECIMAL)
MODBUS
REGISTER
(DECIMAL)
A-B FILE
(DECIMAL)
(NOTE 4)
DESCRIPTION
ACCESS
RANGE
TYPE
500
Module 2 #6 Alarm Level
R/W
40 - 200°C
T1(Low)
501
T1(High)
502
Module 2 #7 Trip Level
R/W
40 - 200°C
T1(Low)
503
T1(High)
504
Module 2 #7 Alarm Level
R/W
40 - 200°C
T1(Low)
505
T1(High)
506
Module 2 #8 Trip Level
R/W
40 - 200°C
T1(Low)
507
T1(High)
508
Module 2 #8 Alarm Level
R/W
40 - 200°C
T1(Low)
509
T1(High)
510
Module 3 #1 Trip Level
R/W
40 - 200°C
T1(Low)
511
T1(High)
512
Module 3 #1 Alarm Level
R/W
40 - 200°C
T1(Low)
513
T1(High)
514
Module 3 #2 Trip Level
R/W
40 - 200°C
T1(Low)
515
T1(High)
516
Module 3 #2 Alarm Level
R/W
40 - 200°C
T1(Low)
517
T1(High)
518
Module 3 #3 Trip Level
R/W
40 - 200°C
T1(Low)
519
T1(High)
520
Module 3 #3 Alarm Level
R/W
40 - 200°C
T1(Low)
521
T1(High)
522
Module 3 #4 Trip Level
R/W
40 - 200°C
T1(Low)
523
T1(High)
524
Module 3 #4 Alarm Level
R/W
40 - 200°C
T1(Low)
525
T1(High)
526
Module 3 #5 Trip Level
R/W
40 - 200°C
T1(Low)
527
T1(High)
528
Module 3 #5 Alarm Level
R/W
40 - 200°C
T1(Low)
529
T1(High)
530
Module 3 #6 Trip Level
R/W
40 - 200°C
T1(Low)
531
T1(High)
532
Module 3 #6 Alarm Level
R/W
40 - 200°C
T1(Low)
533
T1(High)
534
Module 3 #7 Trip Level
R/W
40 - 200°C
T1(Low)
535
T1(High)
536
Module 3 #7 Alarm Level
R/W
40 - 200°C
T1(Low)
537
T1(High)
538
Module 3 #8 Trip Level
R/W
40 - 200°C
T1(Low)
539
T1(High)
540
Module 3 #8 Alarm Level
R/W
40 - 200°C
T1(Low)
541
T1(High)
548
Temperature Trip Action
R/W
0 - 7
T42
549
Temperature Alarm Action
R/W
0 - 7
T43
