SCPC System • System description
CP_SEM_60-03-00.002 17
Mod. Component contains the following service-relevant modules/components:
A SCPC System casing ◗ Touch screen module (B)
◗ Card and module support assembly (C) (sensor modules
and circuit boards)
◗ Mains switch
◗ 2 batteries
◗ Discharge resistor for batteries
◗ Ring core transformer
◗ Rectifier
◗ Mains filter
◗ Fan
◗ Connections:
serial interface, Electrical Remote-Controlled Tubing Clamp,
SCP System
B Touch screen module ◗ Touch-sensitive screen incl. display electronics
◗ CPU (ZDS) circuit board
◗ Interface (ZIS) circuit board
C Card and module
support assembly
◗ Battery monitoring (ZAU) circuit board
◗ Mains monitoring (ZNU) circuit board
◗ Sensor modules (optional, depending on order)
