SCPC System • System description
CP_SEM_60-03-00.002 25
Mod. Item Description Number SP number
C6Module connection CON 1
C7Module connection CON 2
C8Connection for battery monitoring (ZAU) circuit
board
CON 3
C9Connection for mains monitoring (ZNU) circuit
board
CON 4
C10Connection 24 V DC_H_EX (HLM, not used) CON 5
C11Connection U_SEK (from the rectifier) CON 6
C12Fan connection CON 7
C13SCP System connection (external 11)CON 8
See page 15.
C14ERC connection (external 12)CON 9
See page 15.
C15Mains switch auxiliary contact connection CON 10
C16Connection for CPU (ZDS, CON 1) circuit board CON 12
C17Connection 24 V DC_H0 from ZNU circuit board CON 13
C18Connection 24 V DC_L from ZNU circuit board CON 14
C19Connection 24 V DC_L_EX (HLM, not used) CON 15
C20Connection 24 V DC_H0 to automatic circuit
breaker
CON 17
C21Connection 24 V DC_H to automatic circuit
breaker
CON 18
C22Miniature fuse 1 A, slow-blow (+ 12 V DC supply) F 1 93-510-039
C23Miniature fuse 1 A, slow-blow (± 12 V DC supply) F 2 93-510-039
C24Miniature fuse 1 A, slow-blow (5 V DC supply) F 3 93-510-039
