CHAPTER 2: TECHNICAL DATA 17
QUICK LOAD SERVO 80 S2
3. LAYOUT OF THE ELEMENTS
Designation
Description
A
Loading magazine
B
Protection cover
C
Slope setting levers
D
Protection cover holding finger
QS1 Main power switch
A
C
QS1
D
B
