CHAPTER 5: GENERAL DESCRIPTION 61
QUICK LOAD SERVO 80 S2
8. V-EXTENSION KIT 120° (OPTION)
Please read the safety precautions described at the beginning of this manual before handling
the following devices.
Description
This option extends the guiding length of 150 up to 300 mm, by mounting an extension V to the front of the bar
feed; this way, this extension remains completely aligned to the guiding axis of the bar stock.
A front protection cover protects the working gap between the lathe and the bar feed.
Layout of the elements
A Extension V 020.013.033B
B Front protection cover 020.13.071
B
A
