LNS QUICK LOAD SERVO 80 S2 BARFEED - Setting the Top-Cut Position

CHAPTER 6: OPERATION 81
QUICK LOAD SERVO 80 S2
6. AUTOMATIC CYCLE
Bar feeder movement sequences
Sequence
no.
Movement
0 Stop mode and manual functions
1 Production cycle.
2
Loading start.
The pusher returns back to home position.
3 Diameter selection start.
4 The loading table starts moving up
5 The loading flag moves to the bar stock rear.
6 The loading flag pushes the bar stock under the measuring cell SQ3
7 Calculation
8 The loading flag pushes the bar stock behind the clamping device.
9 The loading flag pushes the bar stock to the EOB or to the top cut position.
10 Production cycle with loading table in upper position.
11 The loading flag moves back to home position.
12 The loading table starts moving down.
13 The pusher moves to the bar stock rear.
14 The pusher moves the bar stock behind the clamping device.
15 The pusher positions the bar stock in top cut position
16 In top cut position.
