62 CHAPTER 5: GENERAL DESCRIPTION
QUICK LOAD SERVO 80 S2
9. FRONT PROTECTION COVER (OPTION)
Please read the safety precautions described at the beginning of this manual before handling
the following devices.
Description
In the case the bar feed cannot be mounted very close to the lathe, an adjustable (150 to 300 mm) front
protection cover protects the working gap between the lathe and the bar feed.
Layout of the elements
A Front protection cover
A
