CHAPTER 3: SETTING INTO OPERATION 23
QUICK LOAD SERVO 80 S2
2. MOUNTING
Mounting retraction device
Please read the safety precautions described at the beginning of this manual before
handling the following devices.
Before handling the retraction mechanism, check to see that the interface cables between
the spindle and the bar feed system are long enough
When the bar feed system is ordered with longitudinal retraction system, it is already assembled and fixed
to the machine.
On delivery, the elements of the lateral retraction mechanism are not assembled on the bar feed system.
A Longitudinal retraction for Left/Rear Load
B Lateral retraction for Left/Rear Load
C Longitudinal retraction for Left/Front Load
D Lateral retraction for Left/Front Load
Designation Description
A
B
C
D
E
SQ12
