86 CHAPTER 6: OPERATION
QUICK LOAD SERVO 80 S2
9. REQUEST FOR REFERENCE POINT
This function allows for locating the points of origin of the bar-feed system (positioning)
Before handling the bar feeder, stop the lathe at the end of part cycle.
1
[STOP]
Press the key [STOP].
2
Enter the main menu.
3
[ENTER]
Enter the menu "Misc. applications".
4
[PG DOWN]
Go to the screen "Request for reference point".
5
[BAS]
Press the [ARROW DOWN] for the selected mode.
6
[ENTER]
Press the key corresponding to the icon [ENTER].
7
[ESC]
ou
[STOP]
To exit the set mode, press the keys [ESC] or [STOP].
