CHAPTER 6: OPERATION 67
QUICK LOAD SERVO 80 S2
3. REMOTE CONTROL
The ergonomic and user-friendly remote control with a clear built-in display facilitates the handling of the
bar feed system. Depending on the sequence under way, the bar feed system gives access only to those
functions which are available, thus avoiding any incorrect handling, and reducing the access time to the
necessary functions.
The display reads, continuously and clearly, the status of the bar feed system and the production, allowing
one to verify at all times the functions, diagnostics, error signals, or their analysis. The most recent error
signals are saved in a register and can be recalled to establish the diagnostics.
The remote control has five distinct segments, namely: display (A), function keys (B), directional keys (C),
STOP button (D), and the emergency button (E).
