LNS QUICK LOAD SERVO 80 S2 BARFEED - Application Setup

CHAPTER 6: OPERATION 87
QUICK LOAD SERVO 80 S2
10. APPLICATION SETUP
This machine allows the quick and easy selection of preconfigured applications.
Following working modes are always available:
1. Feeding with turret
2. Feeding without turret
3. Miscellaneous functions (Dry Run, etc.)
Additionally, depending on the lathe and the unlocked functions, following working modes may be available:
4. Work with sub-spindle
5. One shot shaft loading
Following examples describe how to set a simple application. Depending on the unlocked
options, several additional parameters may be added to end the setup.
Working example with feeding with turret, moving to position
1
Enter the main menu.
2
[ENTER]
Main menu:
Enter the menu "application setup".
3
[ENTER]
Application setup menu:
Select the working mode "feed with turret" (default).
4
[ENTER]
Application setup menu: turret management:
Select the parameter "moving to position" (default)
