34 CHAPTER 4: ELECTRICS
QUICK LOAD SERVO 80 S2
AJ1 44.0105 Servo amplifier 400W
FU1 4.419 Fuse 2 Amps for 24 Vdc (motor M3)
FU2 4.877 Fuse 4 Amps for 24 Vdc (motor M2)
K3 4.507 Main contactor
KS 4.985 Start relay
C1 4.884 Capacitor
QF1 4.815 Circuit breaker 4A
QS1 4.242 Main disconnect switch
R1-R5 4.925 Interface relay
T1 4.769 Transformer 1ph
T2 4.779 Transformer + 24 VDC Power supply 150W
