40 CHAPTER 4: ELECTRICS
QUICK LOAD SERVO 80 S2
2.2.6. PLC inputs/outputs
Inputs Outputs
Input Des. Description Output Des. Description
I16 K8 Emergency stop control circuit O48 KA1 Loading table "up" (M2)
I17 SQ10 Main access cover safety switch O49 KA2 Loading table "down" (M2)
I18 SQ11
Loading table cover safety
O50 M3
Diameter change reference
I19 SQ12 Retraction device safety switch O51 M3 Diameter change (M3)
I20 - Not in use O52 K10
Servo motor or
K3
I21 - Not in use O53 - Not in use
I22 - Not in use O54 - Not in use
I23 - Not in use O55 KS Start relay
I24 SQ1
Loading table down position
- - Not in use
I25 SQ3 Measuring cell - - Not in use
I26 SQ4
Diameter change motor
- - Not in use
I27 SQ5
Pusher carrier home position
- - Not in use
I28 - Not in use - - Not in use
I29 - Not in use - - Not in use
I30 - Not in use - - Not in use
I31 M3 Diameter change motor - - Not in use
Interface
I40 A1 Clamping signal from the lathe O56 R1 Relay bar feed alarm
I41 A2 Lathe in AUTO-Cycle O57 R2 Relay loading cycle finish
I42 A3 Start loading signal O58 R3 Relay end of bar
I43 A4 Part feed out signal (option) O59 R4 Relay automatic mode
I44 AX1 Programmable interface input O60 RX1 Programmable interface output
I45 AX2 Programmable interface input O61 RX2 Programmable interface output
I46 AX3 Programmable interface input O62 RX3 Programmable interface output
I47 AX4 Programmable interface input O63 RX4 Programmable interface output
