CHAPTER 6: OPERATION 73
QUICK LOAD SERVO 80 S2
Access to the functions
By pressing the [SET] key (icon ), it is possible to access the setup functions, no matter what cycle the
bar feed is in (automatic sequence, manual sequence, etc.).
To modify these parameters, the bar feed must be in STOP mode. To validate some values
or parameters, hold the [ENTER] key until the icon disappears.
Part setup
Allows to define the parameters and values of the part, like:
· Bar stock shape (round, hex, square, other)
· Bar stock diameter
· Overall part length to feed
· Number of clamping device openings
· Reverse distance of the pusher after feeding
· Overall part length for the auxiliary part (remnant machining)
Application setup
Allows to set quickly the working mode by selecting the desired application.
Following working modes are always available:
1. Feed with turret
2. Feed without turret
3. Misc. functions (Dry Run, etc.)
Depending on the unlocked features and on the lathe, following modes may be
available:
4. Sub-spindle
5. Shaft loading
6. etc.
Position / torque
Quick access to the following position and torque values:
· End of bar
· Top cut
· Auxiliary end of bar
· Torque for the bar stock loading
· Torque for the part feeding
Misc. functions
Allows the access to specific settings like:
· Language
· Measure unit
· Reference
Service
Reserved for maintenance to LNS technicians and for unlocking features /
displays.
MAIN MENU [@]
1:PART SETUP
2:APPLICATION SETUP
3:POSITION/TORQUE
4:MISC. FUNCTIONS
PART
SETUP
APPLICATION
SETUP
POSITION
TORQUE
MISC.
FUNCTIONS
SERVICE
