CHAPTER 6: OPERATION 83
QUICK LOAD SERVO 80 S2
4
[SET]
Press the key corresponding to the icon [SET].
Depending on which sequence the bar feed is in when the parameter is selected, the
available functions and icons can change :
Conditions
Available functions
By offset correction
By teaching
- Loading table down
- No bar stock in the loading
channel
Icon [+/-] Icon [TEACH IN]
- Loading with extended loading
pusher
Icon [+/-] ---
Setting by offset correction: jump to point 5
Setting by teach in: jump to point 6
5
[+/-]
[+/-] By offset correction:
· Press the key corresponding to the icon [+/-].
· The current end of bar position (Z) is displayed.
· Enter with the direction keys the correction to insert, and press the [+] icon
to add the value, or the icon [-] to subtract it. The new value is stored.
· To exit the end of bar set mode, press the key attributed to the icon [ESC].
Jump to point 7.
6
[TEACH IN]
[FWD]
[ENTER]
[TEACH IN] By teaching:
· Press the key attributed to the icon [TEACH IN]. The display shows the
current end of bar position.
· Press the key [FWD] and advance the pusher to the desired position (see
previous page).
· To validate the new end of bar position, keep [ENTER] pressed until the
icon disappears.
7
[ESC]
or
[STOP]
To exit the set mode, press the keys [ESC] or [STOP].
