QUICK START
Logicube ZClone™Xi User’s Manual 13
The Settings screen may be different in each of the modes.
Details on the different Settings screens can be found in
Chapter 5: Types of Operations.
Log file names can be set in Settings in the Job Info screen by
entering a Job Name. See Section 4.3.1 for more information.
5. Tap the Target (or Image File) icon and select the Target or Image File then tap
the OK icon.
For Drive to Image, the ZXi must be used to format
drives. If the Target drive is not formatted by the ZXi, the
Format icon will appear in the Format column. Tap the
(Format) icon to format the Target drive.
6. Tap the Start icon to start the cloning task.
7. A progress bar will appear at the bottom of the screen showing the bytes
processed, the rate (speed), elapsed time, and time remaining.
8. When finished, the status will show “COMPLETED”. At this point, it is
recommended to tap Reset Task to reset the task, so the drive bays properly
reset and not show as being used or assigned for other tasks.
The number of bytes shown on the progress bar
is not the actual size of the drive. This is the
actual bytes being processed. When ‘Verify’ is set
to “Yes”, the reported number will double in size.
3.3 Hash
A hash or operation can be performed to any connected drive. Performing a hash task
will instruct the unit to calculate the hash for the specified drive or validate the hash
value for that drive.
Details on the different screens
found in the Hash operation can
be found in Section 5.3: Hash.
This mode will hash any connected drive on an active Master or Target port. This mode is Logical Block
Address (LBA) based and will hash drives based on the number of LBAs. If multiple drives are selected to
be hashed, the unit will hash up to the LBA value of the smallest capacity drive. If drives with different
capacities need to be hashed, it is recommended to start one task per drive.
