Logicube ZClone Xi User Manual

QUICK START
Logicube ZClone™Xi User’s Manual 21
1. Select Logs from the types of operation on the left side. A list of log files will
appear sorted by date (newest on top).
2. Select the log file to view by tapping the name of the log file. This will highlight
the log file chosen.
3. Tap the View icon to view the log file on-screen. The log files can also be
exported to a USB drive. To export the log files:
a. Connect a formatted USB flash drive to one of the USB 2.0 ports located
in the back panel of the unit. Disconnect any other drive connected to
the USB 2.0 ports.
The USB flash drive connected to the USB
2.0 port must be formatted in Windows
using the NTFS, FAT32, or FAT file system.
b. Tap the Export icon to export the log file to a USB flash drive. The log will
be exported/copied to the attached USB drive and will be in HTML, PDF,
and XML formats.
Repeat steps 2 and 3 if other log files need to be exported or viewed.
Alternatively, all the log files can be exported by tapping the Select All
button to select all the log files. Once all log files are selected, they can be
exported in a single operation.
Log files can also be
accessed over the network.
See Section 3.6.3 for details.
To print the log files, it is recommended to use the web interface as
described in Chapter 7: Remote Operation and click the print icon on the
upper-right corner of the screen. The browser’s print menu will appear, and
the log can be printed to an available printer on configured on the computer.
3.6.2 Deleting Log Files
Log files can be deleted one at a time or all at once.
 To delete a single log file, tap the log file to highlight the log file to be deleted.
Tap the Delete icon to delete the selected log file.
 To delete all the log files, tap the Delete All icon.
A log file deletion password can be set to add a layer of security when deleting log files. If
a password was set, log files cannot be deleted without entering the correct password.
 If a log file deletion password was not created, a confirmation screen will appear
confirming to delete the single log file or all log files.
 If a log file deletion password was created, a screen will appear prompting to
enter the log file deletion password. Enter the log file deletion password. Tap the
OK icon to delete the single log file or all the log files (depending on which was
selected).

Logicube ZClone Xi Specifications

General

Brand	Logicube
Model	ZClone Xi
Category	Disc Duplicator
Language	English
