QUICK START
Logicube ZClone™Xi User’s Manual 22
The password can be set in the Systems Settings.
More information about the log file deletion
password can be found in Section 5.9.2.
3.6.3 Accessing the Logs Over a Network
The log files can also be accessed through a network on a computer if the unit is
connected on the same network.
1. Open Windows Explorer or a similar window and browse to the hostname or the
IP address found in the Statistics screen. See Section 5.7 for more information on
the Statistics screen.
2. A Windows security screen will appear prompting to enter a User name and
Password to connect to the unit. Login with the following credentials:
 User name: it
 Password it
3. Once connected, an auditlog folder will appear. Open the auditlog folder.
4. The auditlog folder contains the HTML, PDF, and XML files for each of the log
files. There will be two folders (html and pdf) that contain either the HTML or PDF
versions of the log files. The XML files can be used with any XML viewer which
allows for some customization on how the information can be viewed.
