22
When saving, one of the following must be selected: Analyzed image, Raw image, or Report.
It is not possible to save only the Bioprocess.
Even if you specify the path as a USB drive, the Bioprocess will be saved only in the internal
memory.
To pr int a text summary of the counting results, make sure a LUNA-FX7™ Thermal Printer
(P17001) is connected to the LUNA-FX7™ and press Print.
The printer should be connected before powering on the instrument.
The printed report will contain the cell count results and protocol details.
Press QUICK SAVE to save results with a default name and suffix designation. The appended
suffix may be a sequential number or the date/time.
Default Quick save preferences may be pre-set in SETTINGS: SAVE & REVIEW.
Instrument : LUNA-FX7 Cell Counter
Serial number : LU7-00-00000
Software version : 0.0.0
Firmware version : 0.0.0
Instrument name : LU7-00-00000
File name : HL60
Date : 16 Apr 2017 14:35:37
Security : Off
User : anonymous
File name : NoTitle
Counting mode : Fluorescence cell counting
Cell lines & Primary cells
Instrument setting
Slide type : 2 channel slide
Counted chamber area : A, B
Autofocusing channel in FL : BF
Autofocused counting : On
Autofocus upon slide insertion : On
Last calibration : 10 Apr 2017 11:45
Calibration value : 24 / 36 / 58 / 100 / 74
Protocol
Protocol name : DEFAULT
GF exposure level : 5
RF exposure level : 5
Cell size calculation: BF
Min. cell size : 3
Max. cell size : 70
GF threshold level : 5
RF threshold level : 5
Dilution factor : 1.11
Size gating: 3 ~ 60 µm
Cell count results
[Total cell] : 1.04 x 10e6 cells / mL
[Live cell] : 9.73 x 10e5 cells / mL
[Dead cell] : 6.62 x 10e4 cells / mL
Viability : 93.6 %
Avg. size : 16.5 µm
Total cell number : 251
Live cell number : 235
Dead cell number : 16
