11. Product Specifications
LUNA-FX7™ Automated Cell Counter
Physical and
Technical
Characteristics
LUNA-FX7™
Basic Package
LUNA-FX7™
Advanced Package
Onboard storage
250 GB
1 TB
Additional software
-
Bioprocess software
Cell size range
1 - 90 µm
Detection range
1 x 10
4
- 5 x 10
7
cells/mL
(Optimal: 5 x 10
4
- 1 x 10
7
cells/mL)
Cell detection method
Automated brightfield & fluorescence microscopy
Slide options
1-Ch, 2-Ch, 3-Ch, 8-Ch, Reusable
Measuring volume per
chamber
0.5 - 5.1 µL/chamber
(Each slide has different measuring volume.)
Optics
Brightfield, Dual fluorescence
Green fluorescence
Ex 470/40 nm, Em 530/50 nm
Red fluorescence
Ex 530/40 nm, Em 620/60 nm
Focusing
Autofocus with manual focus option
Instrument type
Benchtop cell counter
Display
7-inch TFT LCD multi-touch screen, 1024 x 600 pixels
Data format
PDF, CSV, TIFF
Data export
USB, WiFi, Ethernet
Printer
External printer (optional)
21 CFR Part 11
CountWire™ system (optional)
User management
CountWire™ system (optional)
IQ/OQ
Yes (optional)
Dimensions
245 x 280 x 240 mm (9.6 x 11.0 x 9.4 inch)
Weight
5.0 kg (11.02 lb)
Rated line voltage
100 to 240 VAC
Rated input current
1.5 A (at 100 VAC)
Rated input frequency
50 to 60 Hz
Output voltage / current
12 VDC / 5.0 A
LUNA™ Slides
Physical
Characteristics
Compatible
Slides
LUNA™
1-Channel Slides
LUNA™
Cell Counting
Slides /
PhotonSlide™
LUNA™
3-Channel Slides
LUNA™
8-Channel Slides
LUNA™
Reusable Slides
Material
Luna Counting Slide™: Polystyrene (PS)
Other Slides: Poly(methyl methacrylate) (PMMA)
Glass / Aluminum
Dimensions
25 x 75 x 2.1 mm
25 x 75 x 2.3 mm
25 x 75 x 2.1 mm
25 x 75 x 2.1 mm
25 x 75 x 2.5 mm
