Lorex L19WD800 Series - Appendix 1: System Specifications

L19WD Series
53
Appendix 1: System Specifications
Monitor
LCD
19” Widescreen
LCD Resolution
1400x900
Monitor Display
8-ch: Real time: 240/200 FPS (NTSC/PAL)
16-ch: Real Time: 480/400 FPS (NTSC/PAL)
Image Size
1.5 KB (352x240)
Video inputs
1Vp-p, CVBS, 75ohms, BNC (16-ch) / 8 BNC, 4 DIN (8-ch)
Audio inputs
8-ch: 2 x line-in, RCA
16-ch: 4 x line-in, RCA
Audio out
8-ch: 1 x line-in, RCA
16-ch: 1 x line-in, RCA
Audio
2-way Audio conference (via Network)
Supply Voltage
100VAC-240VAC, 12VDC, 6.67A, 50/60Hz
Power consumption
Approx. 80 watts
Temperature range
14˚F ~ 113˚F (-10˚C ~ 45˚C)
Weight
8.8 kg / 19.5 Lbs
Unit dimensions
18.2” / 462mm X 14.5” / 369mm X 2.5” / 62 mm (W x D x H) (without stand)
DVR
Hard disk capacity
Pre-installed SATA HDD (maximum 1000 GB), Security Certified, 100%
duty cycle
Operating System
WinCE 5.0
Secondary Storage
USB Flash drive
Backup file formats
Proprietary
Compression
H.264
Recording speed
352x240: 4-channel 120/100 (NTSC/PAL)
352x240: 8-channel 240/200 (NTSC/PAL)
352x240: 16-channel 480/400 (NTSC/PAL)
Record scheduling
Daily, Weekly, Hourly per 4 channel group
Pre/Post alarm recording
1~5 seconds (pre); 5~99 seconds (post), programmable per 4 channel
group
Event search
Up to 12,000 events
Playback
8-ch: Single, Quad, or 8-channel split-screen
16-ch: Single, Quad, or 9 & 16-channel split-screen
Alarm inputs
8 x TTL, programmable as NC/NO
Alarm outputs
1 x Relay with NC/NO contact; 24V DC/600mA
Activity detection
16x12 grid, Sensitivity levels: 4
PTZ control
RS-485 interface
Remote functions
Live view, Search, Configuration, Playback, Backup
Network Speed Control
4 levels (100KB ~ 2.5MB)/sec
Network protocol
TCP/IP, DDNS and Web
Network interface
10/100-Base-TX, RJ-45
