L19WD Series
71
Appendix 8: Connecting a Spot-Out Monitor
Use the Spot port on the rear panel of the system to connect a Spot Out Monitor (not included).
Spot Out displays the camera channels in sequence. You can change the dwell time for the time
interval in the Interval menu. This is useful for a monitor in public view: you can make people
aware that they are being watched. You can also use the spot-out monitor to display
announcements or advertising. See the Lorex Client Software Manual for more details.
To change time intervals:
1. From the System Main Menu, click
and then click INTERVAL.
2. Under Switching Interval, click ◄► to adjust the dwell time (in seconds) for the Spot
Monitor. The higher the time, the longer the image stays on screen.
3. Click OK to save your settings, or DEFAULT to restore factory defaults.
Connecting an external monitor
Use the Monitor port on the rear panel of the system to connect an external monitor. Monitor-out
mirrors the entire screen image of your system. This is useful if you need to monitor the system
from a second location (e.g. a back office).
SYSTEM
SLAVE MONITOR
(NOT INCLUDED)
PUBLIC VIEW MONITOR
(NOT INCLUDED)
