LSIS XEC-DR64H User Manual

Chapter 8 Built-in High-speed Counter Function
8-23
(1) Parameter setting area
Parameter
Description Device area per channel
Remark
Value Setting
Ch 0 Ch 1 Ch 2 Ch 3
Ch 4 Ch 5 Ch 6 Ch 7
Counter
mode
h0000 Linear count
%KW300 %KW330 %KW360 %KW390
Word
h0001 Ring count
%KW2220 %KW2250 %KW2280 %KW2310
Pulse input
mode
setting
h0000 1 phase 1 input 1 multiplication
%KW301 %KW331 %KW361 %KW391
Word
h0001 1 phase 2 input 1 multiplication
h0002 CW / CCW
%KW2221 %KW2251 %KW2281 %KW2311
Word
h0003 2 phase 4 multiplication
Comp.
Output 0
mode
setting
h0000 (Magnitude) <
%KW302 %KW332 %KW362 %KW392
Word
h0001 (Magnitude) ≤
h0002 (Magnitude) =
h0003 (Magnitude) ≥
h0004 (Magnitude) >
%KW2222 %KW2252 %KW2282 %KW2312
h0005 (Range) Include
h0006 (Range) Exclude
Comp.
Output 1
mode
setting
h0000 (Magnitude) <
%KW303 %KW333 %KW363 %KW393
Word
h0001 (Magnitude) ≤
h0002 (Magnitude) =
h0003 (Magnitude) ≥
h0004 (Magnitude) >
%KW2223 %KW2253 %KW2283 %KW2313
h0005 (Range) Include
h0006 (Range) Exclude
Internal
preset value
setting
-2,147,483,648 ~ 2,147,483,647
%KD152 %KD167 %KD182 %KD197
Double
word
%KD1112 %KD1127 %KD1142 %KD1157
External
preset value
setting
-2,147,483,648 ~ 2,147,483,647
%KD153 %KD168 %KD183 %KD198
Double
word
%KD1113 %KD1128 %KD1143 %KD1158
