LSIS XEC-DR64H User Manual

Chapter 8 Built-in High-speed Counter Function
8-24
Parameter
Description Device area per channel
Remark
Value Setting
Ch 0 Ch 1 Ch 2 Ch 3
Ch 4 Ch 5 Ch 6 Ch 7
Ring counter
min. value
setting
-2,147,483,648 ~ 2,147,483,645
%KD154 %KD169 %KD184 %KD199
DWord
%KD1114 %KD1129 %KD1144 %KD1159
Ring counter
max. value
setting
-2,147,483,646 2,147,483,647
%KD155 %KD170 %KD185 %KD200
DWord
%KD1115 %KD1130 %KD1145 %KD1160
Comp. output
min. value
setting
-2,147,483,648 ~ 2,147,483,647
%KD156 %KD171 %KD186 %KD201
DWord
%KD1116 %KD1131 %KD1146 %KD1161
Comp. output
max. value
setting
-2,147,483,648 ~ 2,147,483,647
%KD157 %KD172 %KD187 %KD202
DWord
%KD1117 %KD1132 %KD1147 %KD1162
Comp. output 0
point
designation
HFFFF No use
%KW320 %KW350 %KW380 %KW410
Word
h0000 %QX0.0.1
h0001 %QX0.0.2
h0002 %QX0.0.3
h0003 %QX0.0.4
h0004 %QX0.0.5
h0005 %QX0.0.6
h0006 %QX0.0.7
h0007 %QX0.0.8
h0008 %QX0.0.9
%KW2240 %KW2270 %KW2300 %KW2330
h0009 %QX0.0.10
h000A %QX0.0.11
h000B %QX0.0.12
h000C %QX0.0.13
h000D %QX0.0.14
h000E %QX0.0.15
h000F %QX0.0.16
