Lucent Technologies -48V CPS4000/CPS4000 PLUS Cabinet Power System
5 - 8 Installation and Testing Issue 13 December 2000
Installing Shelves and Batteries, continued
If J85504D-1
Battery Modules
Are Installed
If battery modules are installed, proceed as follows:
If J85504D-1
Battery Modules
Are Not Installed
If battery modules are not installed, proceed as follows:
If J85504D-1 Battery Modules Are Installed
Step Action
1
Locate the alarm cable (847157674) provided for each battery
module. Install it between either J10, J11, J12, or J13 on the
-48V CPS shelf and P409 on the battery module. One module
alarm cable assembly is required for each battery module.
2
Connect the thermistor assembly to P413 using the
temperature wire set. Locate the thermistor(s) between two
adjacent batteries, as shown on Figure 5-3.
3
Install battery cables to P401 through P408.
4
Using the #6 AWG wire and double-hole lugs provided,
fabricate the cables needed to interconnect the -48V CPS shelf
and battery modules. One set of cables is required for each
battery module. See Table 3-A Note 4 for additional
information.
If J85504D-1 Battery Modules Are Not Installed
Step Action
1
Locate the thermistor(s) between two adjacent batteries, as
shown on Figure 5-3.
Note: Up to four thermistor kit assemblies may be used.
2
Connect the thermistor(s) directly to the CPS shelf J10, J11,
J12, or J13.
