Input Assembly
Hardware
Order cable assemblies for input, output and office alarm connections
from Table 3-E. The table includes both the Lucent Technologies kit and
the commercial equivalent.
Table 3-E: Input Assembly Hardware
List Connector Function
Mating Connection
Lucent Technologies Commercial
21, 21B J1 - J5
Rectifier
Input
100-120Vac
(9A)
200-240Vac
(4.5A)
847415825 Kit provides (5) 14
ft. ac cords with right angle
plugs and wire ties.
Order 1 kit per shelf.
-and-
IEC 320 cord set with
right angle on female
end.
Example: Power
Dynamics
42R02-3212-150 right
angle plug set.
100-120Vac
(9A)
847541638 Kit for use with
847415825 provides (5)
NEMA 5-15 plugs for 120V
service end termination
-or-
(5) 5-15 NEMA plugs
for 120V service
200-240Vac
(4.5A)
847541646 Kit for use with
847415825 provides (5)
NEMA L6-15- plugs for
200-240V service end
termination
(5) NEMA L6-15 plugs
for 200-240V service
end termination
22, 22B J1
Rectifier
Input
847415833 Kit provides (1)
30A input cord, 6 ft.,
consisting of (3) 10 ga wires in
a Heyco 8478 flex conduit.
Order 1 kit per shelf.
(200-240Vac)
10 ga wire set equipped
with (1) Amp
770018-10 housing, (3)
Amp 193797-1 socket,
(2) Amp 641945-1
strain relief, #6-32 x 3/
8” type 8 SH screw,
M310 Daniels
crimping tool
25, 25B J1 - J2
Rectifier
Input
847415833 Kit provides (1)
30A input cord, 6 ft.,
consisting of (3) 10 ga wires in
a Heyco 8478 flex conduit.
Order 2 kits per shelf.
(Dual ac, 200-240Vac)
(2) 10 ga wire sets
equipped with (1) Amp
770018-10 housing, (3)
Amp 193797-1 socket,
(2) Amp 641945-1
strain relief, #6-32 x 3/
8” type 8 SH screw,
M310 Daniels
crimping tool
