Lucent Technologies -48V CPS4000/CPS4000 PLUS Cabinet Power System
Issue 13 December 2000 Alarms, Controls, and Displays 7 - 15
Office Alarm Contacts, continued
J6 Pin
Assignments
Table 7-I gives the office alarm pin assignments on J6.
Table 7-I: Office Alarm Assignments (J6)
Pin Number Office Alarm
1 PMJ_NO
2 PMJ_C
3 PMJ_NC
4 PMN_NO
5 PMN_C
6 PMN_NC
7 BD_NO
8 BD_C
9 BD_NC
10 MJF_NO Ringer/Converter_NO
11 MJF_C Ringer/Converter_C
12 MJF_NC Ringer/Converter_NC
13
14 2ACF_NO/LV_NO
15 2ACF_C/LV_C
16 2ACF_NC/LV_NC
17
18 EARTH_GND
19 AUX_PMJ
20 AUX_PMN
21 BATT
22 ACF_NO
23 ACF_C
24 ACF_NC
25 R_VV
26 R_VI
27 R_RTN
28 R_O/S_IN
29 PBT
30 O/S_RTN
31 EXT_E_GOOD(NO)*
32 EXT_E_COM(C)*
33 EXT_E_ALARM(NO)*
34 EE_ACT_NO*
35 EE_ACT_COM*
36 EARTH_GND
*Applies to ES648A/B/C/BZ control units only.
