Lucent Technologies CPS4000 - Figure 7-1: Module Displays

Lucent Technologies -48V CPS4000/CPS4000 PLUS Cabinet Power System
Issue 13 December 2000 Alarms, Controls, and Displays 7 - 2
Displays, continued
Figure 7-1: Module Displays
Alarm
Alarm
Thermal
Alarm
On
On
Voltage
Current
Standby
Standby
Test
NormalNormal
V
V
AC
Fail
PMNPMN
MJF
PMJPMJ
V AdjV Adj
BD
LED
Test
++
--
Monitor and
Control Unit
(ES646, ES646B,
ES648A, ES648B,
ES648C, ES648BZ)
Ringing Generator
(ES620, ES620B,
ES621, ES621A,
ES621B, ES622B,
ES622C)
Rectifier
(ES660, ES660C)
Converter
(ES680, ES681)
Alarm
Control Unit
(ES647)
LVD Open
Power Power
LVD Fail
Temp Comp
Probe Fail
PMJ PMJ
Output Distribution
with LVD/Thermal
Management Display
(BSP2/BSP2C)
Plug-in Distribution
Module
(ES610, ES613)
Plug-in Distribution
Module
(ES611)
