Lucent Technologies -48V CPS4000/CPS4000 PLUS Cabinet Power System
Issue 13 December 2000 Product Description 2 - 17
Step vs. Slope Module Compatibility
Matching Control
Units With LVD/
Thermal Units
In a -48V plant, keying does not prevent mixing control units and LVD/
thermal boards with different temperature compensation conventions in
the same plant; that is, using slope compensation units with those
equipped with step compensation. This allows units in the field to be
upgraded from step to slope compensation without modification to the
CPS shelf.
Table 2-B matches control units with the proper LVD/thermal unit.
Table 2-B: Slope Module Matrix
Control Units
LVD/Thermal
Unit
Slope Compensation
ES646
ES646B
ES647
BSP2
1
ES648A
ES648B
ES648C
ES648BZ
BSP2C
1
Step Compensation
2
ES640
2
ES640A
2
ES641
2
BSB1
2
1
BSP2 and BSP2C are compatible with ES646, ES646B, ES647, and
ES648 controllers.
2
The step function thermal compensation has been discontinued and
should not be used in equipment currently being manufactured. The
step function units have been discontinued and are no longer
available. Step function equipment is not compatible with currently
manufactured equipment.
