Lucent Technologies -48V CPS4000/CPS4000 PLUS Cabinet Power System
Issue 13 December 2000 Engineering and Ordering 3 - 21
Ordering Information, continued
Torque and Tool
Information for
Output Hardware
Thermal Probes
and Cable
Extension Kits
If the thermistor kits in Table 3-C are not long enough, order an
extension cable from Table 3-J in addition to any of the thermal probes
from Table 3-I.
Table 3-H: Torque and Tool Information for
Output Hardware
Connector Comcode Directions
TB1 847415858
Apply lugs using T&B tool TBM5S; torque
TB1 fasteners to 65 inch-pounds ±10%.
TB2, TB3 847398841
Apply lugs using T&B tool TBM5S; torque
TB1 fasteners to 65 inch-pounds ±10%.
J9 847415841
Apply using Lucent Technologies tools
R4623B, R5250, AMP tools 229378-1,
229764-2, or Lucent Technologies hand tool kit
900533027.
Table 3-I: Thermal Probes
Type Comcode
Paddle 846818706
1/4″ ring 847494606
5/16″ ring type 848194221
Table 3-J: Thermal Probe Cable Kits
Length Comcode
5 feet 847172152
9 feet 847550175
14.5 feet 847548476
17.5 feet 847548468
