Lucent Technologies -48V CPS4000/CPS4000 PLUS Cabinet Power System
2 - 26 Product Description Issue 13 December 2000
Rectifier Plant
Table 2-F: Rectifier Plant Specifications
CPS4000 CPS4000 PLUS
Power Units
ES660 and ES660C rectifiers;
maximum of five units per
shelf or 15 units per plant
ES660 and ES660C rectifiers;
maximum of five units per shelf or
15 units per plant
Control Unit
MCU: ES646, ES646B,
ES648A, ES648B, ES648C,
ES648BZ
ACU: ES647
MCU: ES646, ES646B, ES648A,
ES648B, ES648C, ES648BZ
ACU: ES647
Nominal Output
Voltages
48/52/54.5Vdc 48/52/54.5Vdc
Operating Voltage Range
48-56Vdc
(54.5Vdc - ES660)
48-56Vdc
(58.1Vdc - ES660C)
Maximum Output
Current
75 amperes per shelf (Note 2)
150 amperes per plant
(see Note 1)
75 amperes per shelf (Note 2)
150 amperes per plant
(see Note 1)
Nominal Input Voltage 100/120/200/208/240Vac 100/120/200/208/240Vac
Input Voltage Ranges
90-132Vac
180-264Vac
90-132Vac
180-264Vac
Maximum Input Current
per Rectifier
ES660 Float Mode:
3.3 amperes @ 240Vac
4.6 amperes @ 180Vac
6.9 amperes @ 120Vac
9.7 amperes @ 90Vac
ES660C Float Mode:
4.1 amperes @ 240Vac
5.5 amperes @ 180Vac
8.2 amperes @ 120Vac
11.3 amperes @ 90Vac
ES660C Float Mode:
4.0 amperes @ 240Vac
5.3 amperes @ 180Vac
8.1 amperes @ 120Vac
10.9 amperes @ 90Vac
ES660C Boost Mode:
4.2 amperes @ 240Vac
5.7 amperes @ 180Vac
8.7 amperes @ 120Vac
11.6 amperes @ 90Vac
Continued on next page.
