Lucent Technologies -48V CPS4000/CPS4000 PLUS Cabinet Power System
Issue 13 December 2000 Alarms, Controls, and Displays 7 - 5
Control Units, continued
SW1 Options Switch 1 on the control units provides feature selection as outlined in
Tables 7-B through 7-D. Switch positions 1 and 2 are not used on any of
the control units.
Table 7-B: ES646, ES648A, ES648C SW1 Options
Switch Position Feature
1
N/A
Not used
2
3 Closed
BD alarm also generates a PMJ alarm
3 Open
BD alarm does not generate a PMJ alarm
4 Closed
Enable rectifier On/Standby capability
4 Open
Disable rectifier On/Standby capability
5 Closed
Enable plant battery test
5 Open
Disable plant battery test
6 Closed
Self diagnostics does not send alarms to office
alarm connector
6 Open
Self diagnostics sends alarms to office alarm
connector
Table 7-C: ES646B, ES648B, ES648BZ SW1 Options
Switch Position Feature
1
N/A
Not used
2
3
4 Closed
Enable rectifier On/Standby capability
4 Open
Disable rectifier On/Standby capability
5 Closed
Enable plant battery test
5 Open
Disable plant battery test
6 Closed
Self diagnostics does not send alarms to office
alarm connector
6 Open
Self diagnostics sends alarms to office alarm
connector
