Lucent Technologies -48V CPS4000/CPS4000 PLUS Cabinet Power System
Issue 13 December 2000 Engineering and Ordering 3 - 23
Ordering Information, continued
Spare Parts With the exception of a fan failure, the power units are repaired by
replacement; therefore, each service area needs one set of spares. Table
3-K contains recommended spare parts for the -48V CPS plant. One
each is recommended for each service area.
Table 3-K: Recommended Spares
Unit
Apparatus
Code
Comcode
-48V, 12.5A Rectifier ES660 107076259
-48V, 15A Rectifier ES660C 108286055
48/130V, 4A Converter ES680 107128563
48/24V, 25A Converter ES681 107128571
Monitor and Control Unit (MCU) ES648A 108344490
Monitor and Control Unit (MCU) ES648B 108344508
Monitor and Control Unit (MCU) ES648C 108344516
Monitor and Control Unit (MCU) w/Remote Access/Control Function ES648BZ 108344524
Alarm Control Unit (ACU) ES647 107335069
50VA, 100V, 20Hz Ringing Generator ES620 107138679
50VA, 75V, 25Hz Ringing Generator ES620B 107864845
100VA, 90V, 20Hz Ringing Generator ES621B 108276601
100VA, 80V, 25Hz Ringing Generator ES622B 108407909
100VA, 100V, 20Hz Ringing Generator ES622C 108541517
LVD Circuit Pack BSP2C 108274044
Distribution Module ES610 107266397
Distribution Module ES611 107502825
Distribution Module ES613 107966616
Thermistor Kit (1/4
″
Ring Type Thermal Probe, 9
′
Cable) N/A 847580529
Thermistor Kit (Paddle Type Thermal Probe, 5
′
Cable)
N/A 847198751
5/16
″
Ring Type Thermal Probe/Cable Assembly, 10
′
N/A 848221552
5/16
″
Ring Type Thermal Probe/Cable Assembly, 25
′
N/A 848221560
Thermistor kit for 13Ahr battery N/A 847494606
Intershelf control harness for three shelves N/A 847334794
Intershelf control harness for two shelves N/A 847334786
Thermistor Kit (1/4
″
Ring Type Thermal Probe, 9
′
Cable) N/A 847580529
Thermistor Kit (Paddle Type Thermal Probe, 5
′
Cable)
N/A 847198751
5/16
″
Ring Type Thermal Probe/Cable Assembly, 10
′
N/A 848221552
5/16
″
Ring Type Thermal Probe/Cable Assembly, 25
′
N/A 848221560
MCU/ACU Slot Cover N/A 847345576
DC Fan Cradle Assembly. N/A 847244100
Internal Modem EMC1 108284456
Contactor 100A N/A 847439866
Contactor 150A N/A 847401262
