Lucent Technologies CPS4000 - Table 3-A: -48 V CPS Ordering Information

Lucent Technologies -48V CPS4000/CPS4000 PLUS Cabinet Power System
3 - 6 Engineering and Ordering Issue 13 December 2000
Ordering Information, continued
-48V Cabinet
Power System
Table 3-A: -48V CPS Ordering Information
List No. Description
-48V chassis assemblies; one is always required per shelf. Each chassis assembly provides
five equipment unit slots arranged for ES series power units and distribution modules. Lists
1-4 provide keying functions to prevent insertion of incompatible power units. Select a list
appropriate to the power units required.
1
Output 1: -48Vdc, 75 amperes maximum (using ES660C rectifiers only)
Output 2: 24Vdc, 50 amperes maximum
Arranged for the following apparatus codes:
ES660 and ES660C 48V rectifier
ES681 48/24V converter
ES610 48V fuse distribution module
ES611 48V circuit breaker/fuse distribution module
See Note 2.
2
Output 1: -48Vdc, 75 amperes maximum (using ES660C rectifiers only)
Output 2: 130Vdc, 22 amperes maximum
Arranged for the following apparatus codes:
ES660 and ES660C 48V rectifier
ES680 48/130V converter
ES610 48V fuse distribution module
ES611 48V circuit breaker/fuse distribution module
See Note 2.
3
Output 1: -48Vdc, 75 amperes maximum (using ES660C rectifiers only)
Output 2: Ringing, 100VA maximum
Arranged for the following apparatus codes:
ES660 and ES660C 48V rectifier
ES620 50VA ringing generator (two/power unit slot), or
ES621 100VA ringing generator (two/power unit slot), or
ES621A 100VA ringing generator (two/power unit slot), or
ES621B 100VA ringing generator (two/power unit slot), or
ES622C 100VA ringing generator (two/power unit slot)
ES610 48V fuse distribution module
ES611 48V circuit breaker/fuse distribution module
ES613 ringer fuse distribution module
See Note 2.
