Lucent Technologies -48V CPS4000/CPS4000 PLUS Cabinet Power System
Issue 13 December 2000 Engineering and Ordering 3 - 7
4
Output 1: -48Vdc, 75 amperes maximum (using ES660C rectifiers only)
Output 2: none
Arranged for the following apparatus codes:
ES660 and ES660C 48V rectifier
ES610 48V fuse distribution module
ES611 48V circuit breaker/fuse distribution module
See Note 2.
5 -20 Reserved.
AC input assemblies; one is always required per shelf unless otherwise noted. Each input
assembly is arranged for ac input to the shelf, ES646, ES646B, ES648A/B/C/BZ MCUs, or
ES647 ACU, office alarm output connection, and intershelf signal connection. See Note 3
for conditions of UL acceptability.
21
AC input assembly (initial shelf) wired for and equipped with five pluggable
100-240Vac feeds that power each equipment unit slot separately (true n+1
redundancy). IEC 320 Type Connector. See Note 3.
21B
Same as List 21 except used for the second shelf in a multiple shelf plant. Not
arranged for control unit or office alarm connections. IEC 320 Type Connector.
See Note 3.
22
AC input assembly (initial shelf) wired for and equipped with one pluggable
200-240Vac feed common to all five equipment unit slots. Use only where ac
wiring to the shelf is factory installed. AMP MATE-N-LOCK II Connector. See
Notes 3, 4.
22B
Same as List 22 except used for the second shelf in a multiple shelf plant. Not
arranged for control unit or office alarm connections. Use only where ac wiring
to the shelf is factory installed. AMP MATE-N-LOCK II Connector. See Note 3.
23
Input assembly (initial shelf) without ac input feed for use with converter only
shelf applications. See Note 3.
23B
Same as List 23 except used for the second shelf in a multiple shelf plant. Not
arranged for control unit or office alarm connections. See Note 3.
25
AC input assembly (initial shelf) wired for and equipped with two pluggable
200-240Vac feeds where one powers equipment unit slots 1, 3, and 5 and the
other, slots 2 and 4. Use only where ac wiring to the shelf is factory installed.
AMP MATE-N-LOCK II Connector. See Notes 3, 4.
25B
Same as List 25 except used for the second shelf in a multiple shelf plant. Not
arranged for control unit or office alarm connections. Use only where ac wiring
to the shelf is factory installed. AMP MATE-N-LOCK II Connector. See Note 3.
25R
AC input assembly (initial shelf) wired for and equipped with two 10-ft, 3-10
gauge, 200-240Vac feeds extending from the rear of the shelf. One cable powers
equipment unit slots 1, 3, and 5, the other, unit slots 2 and 4. Cable-end
termination is by the customer. See Note 2 and 3.
25RB
Same as List 25R except used for the second shelf in a multiple shelf plant. Not
arranged for control unit or office alarm connections. Cable-end termination is
by the customer. See Note 2 and 3.
Table 3-A: -48V CPS Ordering Information
List No. Description
