Lucent Technologies CPS4000 - Page 66

Lucent Technologies -48V CPS4000/CPS4000 PLUS Cabinet Power System
3 - 8 Engineering and Ordering Issue 13 December 2000
26
AC input assembly (initial shelf) wired for and equipped with one 200-240Vac
feed common to all five equipment unit slots for installation with ac wiring run
in conduit. May be used where ac wiring to the shelf is field installed or factory
installed. See Note 3.
26B
Same as List 26 except used for the second shelf in a multiple shelf plant. Not
arranged for control unit or office alarm connections. May be used where ac
wiring to the shelf is field installed or factory installed. See Note 3.
27-30 Reserved
DC output assemblies; one is always required per shelf unless otherwise noted. Each
output assembly is arranged for the connection of a maximum of four battery strings or IR
series battery trays, an intershelf power connection, one LVD/thermal BSP2 board, a
maximum of four thermal probe assemblies, and bulk power outputs for outputs 1 and 2.
31
Output assembly applicable for initial shelves with rectifiers without LVD or
slope thermal management.
See Notes 5 and 6.
32 Discontinued Availability
33 Discontinued Availability
34
Output assembly applicable to supplementary shelves in multiple shelf plants,
initial shelves in systems operating without batteries, and to converter only
shelves. Does not provide connection points for batteries or thermal probes. See
Note 5.
35
Output assembly with 100 ampere low-voltage disconnect (LVD) contactor.
Applicable to single-shelf rectifier and rectifier/converter plants and the initial
shelf in plants with rectifiers in the initial shelf only, with slope thermal
management. Applicable to single-shelf rectifier and rectifier/converter plants
and the initial shelf in plants with rectifiers in the initial shelf only. Always
includes a BSP2 or BSP2C board for LVD/slope thermal compensation. See
Notes 5, 6, and 7.
36
Same as list 35 with a 150 ampere low-voltage contactor. Applicable to first
shelf of multiple shelf plants with rectifiers in the first and second shelves.
Always includes a BSP2 or BSP2C board for LVD/slope thermal compensation.
See Notes 5, 6, and 7.
37
Same as list 31 but with slope thermal management. Applicable to single-shelf
rectifier and rectifier/converter plants and the initial shelf in plants with
rectifiers in the initial shelf only. See Notes 5 and 7.
K2 Wire set and cable assembly for connecting two shelves in a two-shelf plant.
K3 Wire set and cable assembly for connecting three shelves in a three-shelf plant.
K4
Adaptor cable required for two-shelf plant where ringers are used in both
shelves.
Table 3-A: -48V CPS Ordering Information
List No. Description
