Lucent Technologies -48V CPS4000/CPS4000 PLUS Cabinet Power System
Issue 13 December 2000 Engineering and Ordering 3 - 9
Ordering Information, continued
Table 3-A Notes 1. These tables describe the arrangement of the chassis assemblies.
List 1: 48V Primary Output, 24V Secondary Output
(See Note 2)
Slot 1 Slot 2 Slot 3 Slot 4 Slot 5
ES660 and/or
ES660C
ES660 and/or
ES660C
ES660 and/or
ES660C
ES681 ES681
Rectifier Rectifier Rectifier Converter Converter
List 2: 48V Primary Output, 130V Secondary Output
(See Note 2)
Slot 1 Slot 2 Slot 3 Slot 4 Slot 5
ES660 and/or
ES660C
ES660 and/or
ES660C
ES660 and/or
ES660C
ES680 ES680
Rectifier Rectifier Rectifier Converter Converter
List 2: 130V Secondary Output (Converter Only Shelf)
(See Note 2)
Slot 1 Slot 2 Slot 3 Slot 4 Slot 5
ES680 ES680 ES680 ES680 ES680
Converter Converter Converter Converter Converter
List 3: 48V Primary Output, Ringing Secondary Output
(see Note 2)
Slot 1A Slot 1B Slot 2 Slot 3 Slot 4 Slot 5
ES620, ES620B,
ES621, ES621A,
ES621B,
ES622B, or
ES622C
ES620, ES620B,
ES621, ES621A,
ES621B,
ES622B, or
ES622C
ES660 and/or
ES660C
ES660 and/or
ES660C
ES660 and/or
ES660C
ES660 and/or
ES660C
Ringer Ringer Rectifier Rectifier Rectifier Rectifier
List 4: 48V Output Only
(see Note 2)
Slot 1 Slot 2 Slot 3 Slot 4 Slot 5
ES660 and/or
ES660C
ES660 and/or
ES660C
ES660 and/or
ES660C
ES660 and/or
ES660C
ES660 and/or
ES660C
Rectifier Rectifier Rectifier Rectifier Rectifier
