Lucent Technologies -48V CPS4000/CPS4000 PLUS Cabinet Power System
Issue 13 December 2000 Installation and Testing 5 - 13
Installing Control Units
Introduction A single control unit can control a one-, two-, or three-shelf plant.
Procedure
Installing Control Units
Step Action
1
Determine whether a Monitor and Control Unit or an Alarm
Control Unit is to be installed.
2
Identify and unpack the control unit.
3
Verify that the Battery on Discharge (BD) threshold on the
control unit is set appropriately. On switch SW440, the
following switch settings support a 51.0V BD threshold: DIP
switches 1, 3, and 5 are closed; switches 2, 4, and 6 are open.
Refer to Table 7-F for all control units.
4
Refer to Table 7-B, 7-C, or 7-D to set switch SW1.
5
Insert the control unit into the left-most slot in the initial CPS
shelf.
6
Using the 3/16 inch Allen wrench, torque the module’s
mounting fastener to a maximum of 12 in-lbs.
