Lucent Technologies -48V CPS4000/CPS4000 PLUS Cabinet Power System
2 - 24 Product Description Issue 13 December 2000
Safety Agency Approvals
Underwriters Laboratories (UL) Listed per Subject Letter
1801: Power Distribution Center for Communications
Equipment
Shelves equipped with AMP MATE-N-LOCK type ac input
connectors are UL Recognized components under Subject
1801 for use in enclosed equipment cabinets.
CPS4000 PLUS: VDE Certification to EN60950 (except
converter configurations)
VDE licensed to VDE0805/EN60950 – see Note 6
Rectifiers, Converters, and Ringers are individually UL
Recognized (UL1950), CSA Certified (CSA 22.2 234) or
evaluated to EN60950 by an EC Notified Body, as
appropriate.
European Economic
Community
(EEC) Directives
EMC Directive 89/336/EEC – see Note 7
Low Voltage Directive 73/23/EEC as amended by Marking
Directive 93/68/EEC – see Note 6
Remote Access Product
Certification
FCC Part 68 Regulatory Statement
CS-03 Canadian Certification
See Note 8.
Note 1: Shelves equipped with one or two ac input feeds are limited to operation at 180 to
264Vac.
Note 2: Bus bars in customer-provided remote distribution and protection modules should be
sized to carry a minimum of 170 amperes at the maximum ambient system temperature.
Note 3: LVD protection per plant is limited to 150 amperes.
Note 4: CPS can withstand temporary fluctuations in temperature up to 75°C (167°F).
Note 5: For altitudes above 5000 feet, derate the temperature by 3.6°F per 1000 feet. For
altitudes above 1524 meters, derate the temperature by 0.656 degrees Celsius per 100 meters.
Note 6: Only the J85500R-1 L4 with (L21, L21B, 22, 22B, 25, 25B, 25R, 25RB, 26, 26B) and
(any output assembly list option from Table 3-A) has been evaluated to the IEC/EN Standards
and are CE Marked.
Note 7: CPS4000 is a Class A EMC product. In a domestic environment this product may
cause radio interference, in which case user may be required to take adequate measures.
CPS4000 PLUS is a Class B EMC product.
Note 8: Refer to Appendix A for the FCC Part 68 Regulatory Statement and to Appendix B for
the Industry Canada Certification.
Table 2-D: -48V CPS4000/CPS4000 PLUS
Electrical Plant Specifications
