Lucent Technologies DDM-2000 OC-12 - Page 1294

Clearing:Trouble363-206-295 TAP-118
7of7Page1997December1,Issue
ON
OFF
1234
Fan Pack #2 removed
Cord
Connector
FAN FAULT
RESET
TEST
1
2
3
4
REPLACE
FILTER
CONTROL
FAULT
Mounting Screws
ALARM
ON
FAULT
POWER
POWER
BA
RESET
Air Flow Sensor
Rivets holding
sensor in place
Area to be cleaned
Air Flow
Sensor
LocationSensorFlowAir—ShelfFanDDM-20002.Figure
