Lucent Technologies DDM-2000 OC-12 User Manual

363-206-295
Technical Specifications
Issue 1 December 1997 10-21
Universal Optical Connector Attenuators 10
The DDM-2000 OC-3 and OC-12 Multiplexers provide Lucent's universal optical
connector on all OLIUs. This connector is a two-part connector consisting of a
faceplate-mounted block and an optical buildout. The faceplate block optionally
supports an ST , SC, or FC-type optical buildout.
A 0 dB ST -type connector is shipped as standard with each OLIU. Optional SC, or FC
0 dB, or attenuated buildouts can be ordered separately as listed in Table 10-12.
Table 10-12 lists single-mode (SM) and multimode (MM) attenuated buildouts.
* 23G and 23H only.
Table 10-12. Universal Buildout Attenuators
Description Connection Loss (dB) Comcode
A3010A ST

0 dB buildout * SM-SM 0 106312523
A3010B ST 5 dB buildout * SM-SM 5 106312556
A3010C ST 10 dB buildout * SM-SM 10 106312572
A3010D ST 15 dB buildout * SM-SM 15 106312598
A3010E ST 20 dB buildout * SM-SM 20 106312630
A3060 SC 0 dB buildout SM-SM & MM-MM 0 106708951
A3060B1 SC 5 dB buildout SM-SM 5 107406142
A3060D1 SC 10 dB buildout SM-SM 10 107406159
A3060F1 SC 15 dB buildout SM-SM 15 107406167
A3070 ST

0 dB buildout SM-SM & MM-MM 0 106795354
A3070B1 ST 5 dB buildout SM-SM 5 107406183
A3070D1 ST 10 dB buildout SM-SM 10 107406191
A3070F1 ST 15 dB buildout SM-SM 15 107406209
A3080 FC 0 dB buildout SM-SM & MM-MM 0 106795404
A3080B1 FC 5 dB buildout SM-SM 5 107406225
A3080D1 FC 10 dB buildout SM-SM 10 107406233
A3080F1 FC 15 dB buildout SM-SM 15 107406241
A2060B SC 5 dB buildout MM-MM 5 106795271
A2060D SC 10 dB buildout MM-MM 10 106795289
A2060F SC 15 dB buildout MM-MM 15 106795297
A2070B ST 5 dB buildout MM-MM 5 106795313
A2070D ST 10 dB buildout MM-MM 10 106795321
A2070F ST 15 dB buildout MM-MM 15 106795339
