Administration and Provisioning
8-38 Issue 1 December 1997
Switch Selectable Parameters 8
Table 8-10 describes the parameters provisionable via hardware switches. Refer
to the command pages in Section 11, "Commands and Reports," for a complete
explanation of parameters. Additional information on the shelf and other
parameters is provided in the "Identifiers" part immediately following Table 8-11.
Table 8-10. Parameters Provisionable via Hardware Switches
Parameter Range Pack
Command
(Note)
Product ID (S1) "Product Type" SYSCTL rtrv-ne
Optical transmitter power high, low 21G/21G-U OLIU rtrv-oc3
DS1 reference format ∗
DS1 reference line coding ∗
Shelf timing mode
SYNC output LBO †
DS1 Output
SF, ESF
AMI,B8ZS
free-running, external DS1, line timed
5 settings (cable dependent)
MULT/SYNC OUT
TG
TG
TG
TG
TG
rtrv-sync
rtrv-sync
rtrv-sync
rtrv-sync
rtrv-sync
3DS3 LBO 2 settings (cable dependent) 3DS3
3STS1E LBO 2 settings (cable dependent) 3STS1E
Note: Current switch settings except 3STS1E LBO, SYNC Output LBO, 3DS3 LBO, and TBOS
termination can be reported using CIT.
∗ For both DS1 in and out.
† Operational only when in SYNC OUT mode.
