363-206-295
A SONET Overview
Issue 1 December 1997 A-7
Line Overhead 1
Line Pointer (H1, H2)
Two bytes indicate the offset in bytes between the pointer action
byte (H3) and the first byte (J1) of the STS-1 synchronous payload
envelope (SPE).
Pointer Action (H3)
One byte is allocated for frequency justification.
Line Bit-Interleaved Parity (BIP-8) (B2)
This byte is for line performance monitoring. This byte is provided in
all STS-1 signals within an STS-
N
signal.
Line Automatic Protection Switching (APS) (K1, K2)
Two bytes used for APS signaling between line level entities. In
addition, bits 6, 7, and 8 of K2 are used for line alarm indication
signal (AIS) and line far-end receive failure (FERF). Defined only for
STS-1 #1 of an STS-
N
signal.
Line Data Communications Channel (D4 - D12)
Is a 576 kb/s message-based channel.
Synch. Status (S1)
In STS-1 #1, the S1 byte is for synchronization status messages,
and only bits 5 through 8 are used.
Line REI (M0)
The M0 byte is for STS-1 line far-end block error (FEBE), and only
bits 5 through 8 are used.
Line Orderwire (E2). Defined only for STS-1 #1 of an STS-
N
signal.
One byte is allocated to be used as an express orderwire between
line terminating equipment.
