Issue 1 December 1997 xxix
Figures
2 Applications
2-1 Path Switched Ring 2-5
2-2 OC-12 Path Switched Ring — STS-1 Level Path
Switching 2-6
2-3 OC-12 Path Switched Ring Using OC-12
Multiplexer—Mixed STS-1 and VT1.5
Path Switching 2-7
2-4 OC-3 Ring with OC-12 Ring Transport 2-8
2-5 Multinode OC-3 Ring With OC-12 Ring
Transport 2-10
2-6 DDM-2000 OC-12 Path Switched Interoffice
Ring 2-11
2-7 Folded Ring Configuration 2-13
2-8 OC-3 Ring Transport on OC-12 Point-to-Point 2-14
2-9 Dual Access Configuration 2-16
2-10 Dual Ring Interworking Concepts 2-17
2-11 OC-3/12 to FT-2000 OC-48 Lightwave System
Dual Ring Interworking 2-19
2-12 DDM-2000 Ring Interworking with FT-2000
OC-48 Lightwave System Transport and
DACS IV-2000 Grooming 2-21
2-13 OC-3 Services Using Linear Optical Extensions 2-23
2-14 OC-12 Point-to-Point Loop Configuration
(Folded Ring) 2-24
2-15 OC-12 Point-to-Point Interoffice Configuration
(Folded Ring) 2-25
2-16 OC-3 Loop Carrier Interface Configuration 2-26
2-17 OC-12 Ring Interfaces with FT-2000 OC-48
Lightwave System 2-27
2-18 Interworking of OC-1/OC-3/OC-12/OC-48
with Tellabs TITAN 5500 DCS 2-28
2-19 Self-Healing Medical Campus Network
Application 2-31
2-20 STS-3c Video Broadcast Application 2-32
2-21 STS-3c Video Broadcast Application for ATM
Interface 2-33
